HackRF One(1MHz-6GHz) Software Radio Platform SDR Development Board Open Source SDR Radio Platform

• weight: 485 g

Features:

Wide Frequency Range: HackRF One operates in a wide frequency range from 1MHz to 6GHz, giving you incredible versatility for all types of RF exploration.



High Sample Rate: With a sample rate of up to 20 million samples per second, HackRF One can capture a wide spectrum of RF signals.



Open-Source Hardware: HackRF One is open-source hardware, designed to be used as a USB peripheral or standalone RF equipment.



Software Compatibility: HackRF One is compatible with a multitude of software like GNU Radio and SDR#, making it a flexible tool for all your needs.



Advanced Controls: The board has software-configurable RX and TX gain and baseband filters, software-controlled antenna port power, and convenient programming buttons.



USB-Powered: HackRF One is powered via USB 2.0, making it easy to use with any compatible device.



Specifications:

Operating Frequency: 1 MHz to 6 GHz

Transceiver: half-duplex

Sample Rate: up to 20 million samples per second

Quadrature samples: 8-bit I and 8-bit Q

Antenna Connector: SMA female

Clock Input and Output: SMA female

USB: Hi-Speed USB 2.0

Power Source: USB-powered



Package Includes:

1 x HackRF One (enclosed in an injection molded plastic enclosure)

1 x Micro USB Cable (100CM / 39 INCH)

1 x SMA Antenna
